Sawing & Cutting Machines

For all your metallurgical manufacturing needs, we offer durable, efficient and affordable sawing and cutting machines.
Contact Us

Blades & Band Saws

With IDEAL bandsaw blades, you will reduce your cutting and manufacturing costs considerably. These blades offer productivity and longevity. Quick delivery! 1 to 3 days for any product already in stock
Contact Us

Industrial Lubricants & Filtration

The widest range of industrial lubricants to meet all your requirements: environmental, to reduce your costs, for your employees' safety or performance.
Contact Us

Tribofinishing & Deburring Machines

A wide range for all your finishing, polishing and deburring needs. Montfort International Ltd offers a wide range of high-performance tribofinishing machines and sanding tools to increase your productivity and reduce costs.
Contact Us

Industrial Equipment

Let our qualified staff guide you to high-performance equipment that will allow you to increase your productivity and the quality of your products.
Contact Us

Machine Safeguarding & Modular Machine Guards

Online sale of industrial safety equipment and turnkey installation service of perimeter safety guarding systems for hazardous areas.

Roty-Tyro CP 25T Automatic Drilling Machine with Touch Numerical Control

CP 25-T is the ideal CNC vertical drilling machine with numerical touch-controlled and is suitable for repetitive fixed or variable pitch drilling of any type of profile (round, square, rectangular), and of any type of material: flat iron, steel, stainless steel or plastic. The”Tube drilling” optimisation functions make CP 25-T the productive machine par excellence.
Quote request
A multidisciplinary team to accompany you in your projects
A remarkable After-Sales Support
Unrivaled quality and a customized product

Drilling Machine with Tactile Numerical Control

The CP 25-T drilling machine is suitable for repetitive fixed or variable pitch drilling of any type of profile (round, square, rectangular), and of any type of material: flat iron, steel, stainless steel or plastic.

Very easy to use, after starting the cycle on the touch panel, the head is lowered automatically. The operator loads the profile into the feeding clamp and can start production automatically.

Working on the bars avoids all manual handling and gives the machine great autonomy.

Features

  • Drilling capacity on steel 60 kg: Ø 25mm.
  • Cone: CM3
  • Ø column: 100mm, Ø spindle: 80mm
  • Spindle stroke: 125mm
  • Motor : 1,5 HP
  • Speed: 80 to 3000 rpm with an electronic speed controller. Speed display
  • Spindle stroke by brushless servomotor
  • Brushless: adjustable from 0,01 à 1 mm/turn – fast at 50 mm/min.
  • Pneumatic clamp, maximum opening: 200 mm, maximum distance between rear jaw/ spindle axis: 100 mm.
  • Adjustable back jaw by screw, wheel and mechanical digital display (position in Y).
  • Conversational programming by entering requested values.
  • Optional tapping functions

Feeding by Numerical Command (Position in X)

  • Carriage guidance by precision rollers on hardened and ground guides (63 HRC)
  • Support table 200mm wide, made of extruded aluminium with rollers Ø40 mm, 200mm pitch. Safety metal sheets between rollers.
  • Pneumatic clamp with adjustable opening: 0 to 200mm
  • Close-loop servo control
  • Automatic adjustment of the rack & pinion play
  • Precision : ± 0,1 per meter
  • Carriage stroke : 2000 to 8000 mm (standard)
  • Adjustable carriage speed: 0 to 24m/min
  • Pull wire emergency stop switch.
  • Power supply: 230V mono
  • 8’’ colour touch screen.
  • Menus accessible at all time by tabs.

Options

  • Power supply: 400 V
  • Lighting 24V
  • Ethernet connection kit+ software
  • Lubrification by pneumatic spraying
  • Remote Control WIFi
  • Horizontal roller conveyor
