LESTHER F2C-360 ACN Column Type Automatic bandsawing Machine

Name: LESTHER F2C-360 ACN - Automatic Sawing machine
SKU: LES-F2-360AW
Availability: InStock

The Lesther F2C-360 ACN is a column type full automatic bandsawing machine with an independent feed bed and vice system to provide accurate cutting.

Quote request

A multidisciplinary team to accompany you in your projects

A remarkable After-Sales Support

Unrivaled quality and a customized product

SKU: LES-F2-360AW Categories: Sawing & Cutting Machines, Automatic Bandsaws

Print in PDF

Send by email

Documentation

LESTHER Catalogue - FR & EN

Column Type Full Automatic Bandsaw

Our Lesther brand brings you the ACN F2C-360, an effective quality bandsaw for sawing metals and pipe joints. Fully automatic, it comes with a chip conveyor and provides remarkable precision with its independent feed and vice systems.

Features

Independent feed bed and vice system to provide accurate cutting
Both rear vice jaws are fitted with retract on the return stroke to allow feeding of deformed or bent meterials and to prevent scoring of material
Full Stroke hydraulic vice clamps
Split vise clamping system
P.L.C. control system.
Hydraulic blade tension holds proper tension for cuts and releases it upon shut-off which keeps the blade life.
Variable blade speed control
Automatic chip conveyor
Motion detector to shut the machine down in case of blade breakage or jam

Standard Equipment

Hydraulic blade tension
Variable blade speed
Automatic chip conveyor

Optional Equipment

NC control system
Nesting fixture
Vise pressure regulator
Roller table

Technical Specifications

Model		F2C-360 ACN
Cutting Capacity (mm)	● 90°	360
Cutting Capacity (mm)	▬ 90°	▬ 90°	360 x 360
Motors	Blade	3.75 KW
	Hydraulic	Hydraulic	0.75 KW
	Coolant	Coolant	0.1 KW
Blade size		174" x 1-1/4" x 0.42" (4430 x 34 x 1.1 mm)
Blade speed (M/min)		20 - 120
Single Feed Stroke (mm)		500
Working Height (mm)		660
Packing Dimensions (mm)	Length	1750
	Width	Width	2300
	Height	Height	1900
Net Weight (approx.) kg		2200
